Name: Allied Telesis AT-CV5001AC power supply unit 140 W 2U Grey
Brand: Allied Telesis
SKU: AT-CV5001AC
Price: 681.80 CAD
Availability: InStock

888-370-2261 info@itlogixs.ca 157 Edith Way NW, Calgary, AB, T3R 2B8

Home /Computers & IT Hardware /Power & UPS /Allied Telesis AT-CV5001AC power supply unit 140 W 2U Grey

Product Details

The AT-CV5001AC is a hot swappable power supply module for the AT-CV5001 18 slot Converteon chassis. Up to 2 power supply modules can be installed in the chassis to provide resiliency and increase up time.

Product Specifications

Manufacturer	Allied Telesis
Manufacturer Part Number	AT-CV5001AC
Brand Name	Allied Telesis
Product Name	Allied Telesis AT-CV5001AC power supply unit 140 W 2U Grey

Power
Mfr. Part Number	AT-CV5001AC
Total power	140 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	3 A
Performance
Power supply unit (PSU) form factor	2U
Mean time between failures (MTBF)	64000 h
Design
Product colour	Grey
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	32 - 104 °F
Certificates
Certification	FCC A, EN55022 A, VCCI A, C-Tick, CE
Safety regulation & standards
Safety	UL60950-1 (cULUS), EN60950-1 (TUV)
Weight & dimensions
Weight	1.72 kg
Other features
Dimensions (WxDxH)	191 x 191 x 67 mm
Operating altitude	0 - 3048 m
Power supply type	AC
Weight (imperial)	1.72 kg (3.8 lbs)
Electromagnetic immunity	EN55024
Brand	Allied Telesis
Availability	In Stock
Price Currency	CAD
Category	Power & UPS
