ATEN 2 Port True 4K HDMI Splitter VS82H
CA$134.99
Save 5%
CA$128.23
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The ATEN VS82H splitter offers you superior video resolution of True 4K and lossless quality when sending one source of digital high-definition video to two displays. It supports HDMI-enabled equipments from DVD players, satellite set-top boxes to all HDMI displays.
Aside from being HDCP 2.2 compliant, the VS82H comes with automatic EDID detection that always presents users with the best resolution across different screens. Along with support for Dolby TrueHD and DTS-HD Master 7.1 Audio channel, the VS82H ensures you distortionless and outstanding audio quality.
What’s more, the VS82H is a bus-powered splitter that can be charged directly from a device connected through Micro-USB port. Integrating the above functionalities provides you an effective solution for personal, corporate, educational and commercial applications.
Aside from being HDCP 2.2 compliant, the VS82H comes with automatic EDID detection that always presents users with the best resolution across different screens. Along with support for Dolby TrueHD and DTS-HD Master 7.1 Audio channel, the VS82H ensures you distortionless and outstanding audio quality.
What’s more, the VS82H is a bus-powered splitter that can be charged directly from a device connected through Micro-USB port. Integrating the above functionalities provides you an effective solution for personal, corporate, educational and commercial applications.
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | VS82H |
| Brand Name | ATEN |
| Product Name | ATEN 2 Port True 4K HDMI Splitter |
| Mfr. Part Number | VS82H |
|---|---|
| Ports & interfaces | |
| Video port type | HDMI |
| Video out | 2x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 2 |
| Features | |
| Product colour | Black |
| Housing material | Aluminium |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Yes |
| Maximum operating distance | 5 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 600 MHz |
| HDCP version | 2.2 |
| LED indicators | Status |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| Power | |
| AC input voltage | 5 V |
| Power consumption (typical) | 1.35 W |
| USB powered | Yes |
| Weight & dimensions | |
| Width | 60 mm |
| Depth | 150 mm |
| Height | 88 mm |
| Weight | 120 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 59 mm |
| Package depth | 119 mm |
| Package height | 160 mm |
| Package weight | 196 g |
| Packaging content | |
| Manual | Yes |
| Cables included | Micro-USB |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Logistics data | |
| Master (outer) case net weight | 4.8 kg |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 315 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 338 mm |
| Master (outer) case gross weight | 8.36 kg |
| Products per master (outer) case | 40 pc(s) |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Cables & Connectivity |
