ATEN
ATEN CE610A KVM extender Transmitter & receiver
CA$1,202.99
Save 5%
CA$1,146.16
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.
The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and fi le transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.
The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and fi le transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required.
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | CE610A |
| GTIN / Barcode | 0672792007163 |
| Brand Name | ATEN |
| Product Name | ATEN CE610A KVM extender Transmitter & receiver |
| Mfr. Part Number | CE610A |
|---|---|
| GTIN / Barcode | 0672792007163 |
| Features | |
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum digital resolution | 1920 x 1200 pixels |
| Material | Metal |
| LED indicators | Link, Power, USB, Video |
| Transmitter | |
| RJ-45 ports quantity (transmitter) | 2 |
| Ports & interfaces | |
| USB 2.0 ports quantity | 3 |
| USB data transfer rates | 40 Mbit/s |
| Power | |
| Power consumption (transmitter) (max) | 15 W |
| Weight & dimensions | |
| Transmitter width | 11.8 cm |
| Transmitter depth | 18.2 cm |
| Transmitter height | 2.87 cm |
| Transmitter weight | 620 g |
| Receiver width | 11.8 cm |
| Receiver depth | 18.2 cm |
| Receiver height | 2.87 cm |
| Receiver weight | 620 g |
| Packaging content | |
| AC adapter included | Yes |
| Cables included | DVI, USB |
| Manual | Yes |
| Mounting bracket(s) included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Other features | |
| Firmware upgradeable | Yes |
| Technical details | |
| Video in | DVI-D |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Cables & Connectivity |
