ATEN CE611 KVM extender Transmitter & receiver
CA$831.99
Save 5%
CA$792.81
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The ATEN CE611 is a USB DVI HDBaseT™ KVM Extender that integrates the latest HDBaseT™ technologies to transmit 1920 x 1200 DVI video, stereo audio, USB, and RS-232 signals up to 100 meters using a single Cat6 / 6a cable / ATEN 2L-2910 Cat 6 cable. This cost-effective extender comes with a small form factor design that includes DVI/audio interfaces, USB 2.0 full-speed ports, and serial console to fulfill most of extended KVM control and console demands. With an easy cable installation that supports various signals, the CE611 is ideal for applications where convenient remote access is required, such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | CE611 |
| GTIN / Barcode | 0672792010408 |
| Brand Name | ATEN |
| Product Name | ATEN CE611 KVM extender Transmitter & receiver |
| Mfr. Part Number | CE611 |
|---|---|
| GTIN / Barcode | 0672792010408 |
| Features | |
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 100 m |
| Cable types supported | Cat6, Cat6a |
| Maximum digital resolution | 1920 x 1200 pixels |
| Supported resolutions | 1920x1200 1920x1080 1600x1200 |
| Product colour | Black |
| Material | Metal |
| LED indicators | Yes |
| Certification | RoHS |
| Transmitter | |
| Transmitter video port type | DVI-D |
| Transmitter local keyboard/mouse port type | USB |
| RJ-45 ports quantity (transmitter) | 1 |
| Receiver | |
| Receiver local video port type | DVI-D |
| Receiver local keyboard/mouse port type | USB |
| RJ-45 ports quantity (receiver) | 1 |
| Ports & interfaces | |
| USB data transfer rates | 480 Mbit/s |
| RS-232 ports | 2 |
| RJ-45 ports quantity | 2 |
| PC Audio in | Yes |
| PC Audio out | Yes |
| Power | |
| Power consumption (transmitter) (max) | 2.494 W |
| Power consumption (receiver) (max) | 4.816 W |
| Weight & dimensions | |
| Transmitter width | 12.8 cm |
| Transmitter depth | 8.69 cm |
| Transmitter height | 2.5 cm |
| Transmitter weight | 350 g |
| Receiver width | 12.8 cm |
| Receiver depth | 8.69 cm |
| Receiver height | 2.5 cm |
| Receiver weight | 340 g |
| Packaging content | |
| AC adapter included | Yes |
| Manual | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Other features | |
| Firmware upgradeable | Yes |
| Technical details | |
| Power requirements | DC |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Cables & Connectivity |
