ATEN
ATEN CS231 KVM switch Silver
CA$320.99
Save 5%
CA$305.53
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The CS231 is a powerful, micro-processor controlled computer sharing device. It is a multi-user, single-tasking device that enables two users to share the use of a single computer - each from their own consoles (monitor, keyboard, and mouse).The CS231 supports USB consoles and both PS/2 and USB computers
Features:
-Single computer is shared by two USB consoles.
-Supports USB and PS/2 computers.
-Multiplatform Support (Windows, Mac, Unix, Linux).
-Manual or Auto console selection.
-On-Screen-Display informs user when system is in use.
-No Software required.
-Private Mode for a privileged user.
-Screen saver function.
-Supports VGA, SVGA Multisync monitors.
-Firmware Upgradable.
-Multiplatform support: Windows 2000/XP/Vista, Linux, Mac and Unix.
Package Contents
1x Computer Sharing Device
1x Custom KVM Cable (VGA, USB; 1.8m/6ft)
1x Power Adapter
1x Firmware Upgrade Cable
1x DIP Switch Sticker
1x User Instructions
Features:
-Single computer is shared by two USB consoles.
-Supports USB and PS/2 computers.
-Multiplatform Support (Windows, Mac, Unix, Linux).
-Manual or Auto console selection.
-On-Screen-Display informs user when system is in use.
-No Software required.
-Private Mode for a privileged user.
-Screen saver function.
-Supports VGA, SVGA Multisync monitors.
-Firmware Upgradable.
-Multiplatform support: Windows 2000/XP/Vista, Linux, Mac and Unix.
Package Contents
1x Computer Sharing Device
1x Custom KVM Cable (VGA, USB; 1.8m/6ft)
1x Power Adapter
1x Firmware Upgrade Cable
1x DIP Switch Sticker
1x User Instructions
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | CS231 |
| Brand Name | ATEN |
| Product Name | ATEN CS231 KVM switch Silver |
| Mfr. Part Number | CS231 |
|---|---|
| Ports & interfaces | |
| Number of computers controlled | 1 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA |
| Console ports | USB A, VGA (D-Sub) |
| Console USB ports quantity | 4 |
| USB 2.0 ports quantity | 4 |
| DC-in jack | Yes |
| Performance | |
| Maximum resolution | 1920 x 1440 pixels |
| Firmware upgradeable | Yes |
| Design | |
| Rack mounting | No |
| Product colour | Silver |
| Housing material | Metal |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Display | |
| Built-in display | No |
| On Screen Display (OSD) | Yes |
| Power | |
| Power source | DC |
| Input voltage | 5.3 V |
| Power consumption (typical) | 2.2 W |
| System requirements | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | Yes |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 88 mm |
| Height | 55.5 mm |
| Weight | 560 g |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Network Switches |
