ATEN
ATEN VE802T AV extender transmitter Black
CA$254.99
Save 5%
CA$242.58
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The VE802T HDMI HDBaseT-Lite Transmitter connects with HDBaseT receivers* to extend signals up to 70m from the source using one Cat 5e/6/6a cable. It supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE802R) while also granting access to the HDMI display device from the local unit (VE802T). IR signals can also be extended in both directions. The VE802T features Power over HDBaseT (POH) which can send power over Cat 5e/6/6a cable without an additional power supply. The VE802T is HDMI (3D, Deep Color,4k) and HDCP compatible. The VE802T is perfect for a digital entertainment center or any installation that requires superior video quality.
* Compatible HDBaseT Reciver Units: VE802R
* Compatible HDBaseT Reciver Units: VE802R
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | VE802T |
| GTIN / Barcode | 0672792006203 |
| Brand Name | ATEN |
| Product Name | ATEN VE802T AV extender AV transmitter Black |
| Mfr. Part Number | VE802T |
|---|---|
| GTIN / Barcode | 0672792006203 |
| Features | |
| Type | AV transmitter |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 70 m |
| Supported video modes | 2160p |
| Supported graphics resolutions | 4096 x 2160 |
| Bandwidth | 340 MHz |
| HDCP | Yes |
| Material | Metal |
| Consumer Electronics Control (CEC) support | Yes |
| Impedance | 100 Ω |
| Product colour | Black |
| Ports & interfaces | |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| RS-232 output ports | 1 |
| Audio input | 1 |
| Audio output | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
| Power | |
| AC input frequency | 60 Hz |
| Operating voltage | 5 V |
| Power consumption (transmitter) (max) | 3.6 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Transmitter dimensions (WxDxH) | 123 x 144.8 x 30 mm |
| Transmitter weight | 440 g |
| Packaging content | |
| Manual | Yes |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Computers & IT Hardware |
