ViewSonic
Viewsonic CDE4312-E1 Signage Display Digital signage flat panel 109.2 cm (43") LED Wi-Fi 230 cd/m² 4K Ultra HD Black Built-in processor 16/7
Mfr. Part# CDE4312-E1
CA$901.99
CA$859.06
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
| Manufacturer | ViewSonic |
|---|---|
| Manufacturer Part Number | IFP8662 |
| GTIN / Barcode | 0766907012088 |
| Brand Name | ViewSonic |
| Product Name | Viewsonic IFP8662 Signage Display Interactive flat panel 2.18 m (86") LED Wi-Fi 350 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 8.0 |
| Mfr. Part Number | IFP8662 |
|---|---|
| GTIN / Barcode | 0766907012088 |
| Display | |
| Panel type | TFT-LCD |
| LED backlight | Yes |
| Display diagonal | 2.18 m (86") |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 350 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Touchscreen technology | Ultra Fine Touch (UFT) |
| Number of simultaneous touchpoints | 20 |
| Multi-touch | Yes |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 5000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Active display area (W x H) | 1895.04 x 1065.96 mm |
| Surface hardness | 9H |
| Ports & interfaces | |
| HDMI ports quantity | 5 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 1 |
| DVI port | No |
| VGA (D-Sub) input ports | 1 |
| USB port | Yes |
| USB ports quantity | 9 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB 2.0 Type-B ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| PC Audio in | Yes |
| Microphone in | Yes |
| RS-232 interface | Yes |
| Digital audio optical out | 1 |
| PC Audio out | Yes |
| OPS module slot | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 24 W |
| Design | |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Yes |
| Bezel width (bottom) | 6.39 cm |
| Bezel width (side) | 3.15 cm |
| Bezel width (top) | 3.88 cm |
| Anti-glare screen | Yes |
| Performance | |
| Purpose | Universal |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power | |
| Power consumption (typical) | 160 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 580 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 200 kWh |
| AC input voltage | 100 - 240 V |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Built-in processor | Yes |
| Processor architecture | ARM Cortex-A73 |
| Processor frequency | 1.2 GHz |
| Processor cores | 4 |
| Internal memory | 3 GB |
| Internal storage capacity | 32 GB |
| Operating system installed | Android 8.0 |
| Windows operating systems supported | Yes |
| Weight & dimensions | |
| Display width | 1960 mm |
| Display depth | 80 mm |
| Display height | 1171 mm |
| Display weight | 63.7 kg |
| Weight | 63.7 kg |
| Packaging data | |
| Package width | 2123 mm |
| Brand | ViewSonic |
